The Centurion’s D10 SMART commercial and heavy industrial sliding gate motor are suitable for gates weighing up to 1000kg. Furthermore, it can be used for up to 750 daily operations. On the other hand, it comes with a 24V battery backup to be used in case of a power blackout. D10 Smart Gate in Kenya is the latest development of smart gates systems from Centurion’s Systems.
At Premier Automatic Gates Systems, we have trained and professional installers of sliding gates in Kenya
Call | Text | WhatsApp 0722 708034 / 0720 456534 / 0725 790734
Main features of D10 Smart Sliding Gate System:
- Taking intelligence to the next level – a machine crafted for excellence and perfected through innovation
- Pushing the limits of technology to bring you the ultimate in strength, security and endurance – suitable for gates weighing up to 1t with 750 daily operations
- SMART hardware and SMART connectivity provide the best experience for installers
- Intelligent theft and break-in protection with an integrated vibration sensor and patented theft-deterrent cage
- More space and dedicated accessory tray for complementary solutions such as GSM devices
- World-class reliability with a sealed gearbox and improved more secure manual release mechanism
- Die-cast aluminium gearbox coupled with a high-torque DC motor built for pure power and performance
- Uncompromising security, uninterrupted convenience with 24V battery backup
- Instant access to advanced, in-app diagnostics and logs, monitoring system health in real-time
- Accurate and safe position control incorporating reliable Hall Effect technology
- Improved wire routing
- SMART universal controller – compatible with all CENTURION SMART solutions.
Technical Specifications:
| D10-SMART | D10 TURBO-SMART | ||
|---|---|---|---|
| Input voltage | 90V – 240V AC +/-10% @ 50Hz *1 | 90V – 240V AC +/-10% @ 50Hz *1 | |
| Current consumption (Mains) | 250mA | 250mA | |
| Battery charger current output | 1.8A @ 27.4V +/-1% | 1.8A @ 27.4V +/-1% | |
| Maximum number of operations per day | 750 *(3,6) | 750 *(3,6) | |
| Duty cycle – Mains present2,3 | 45% | 25% | |
| Motor voltage | 24V DC | 24V DC | |
| Motor power supply | Battery-driven (Standard Capacity – 2x 12V 7.2Ah) | Battery-driven (Standard Capacity – 2x 12V 7.2Ah) | |
| Current consumption (motor at rated load) | 8A | 10A | |
| Input / Output sink currents (Max accessory current draw) | |||
| I/O 1-4 | 100mA (12/24V) | 100mA (12/24V) | |
| I/O 5 and 6 | 3A (12/24V) 10sec Pulse | 3A (12/24V) 10sec Pulse | |
| Motor push force – starting | 40Kgf | 24Kgf | |
| Motor push force – rated | 30Kgf | 18kgf | |
| Gate mass – maximum | 1000Kg | 250kg8 | |
| Gate length – maximum | 50m | 50m | |
| Gate speed (varies with load)4 | Up to 26m/min4 | Up to 45m/min8 | |
| Manual Override | Lockable with key release | Lockable with key release | |
| Drive Pinion | 17T Module 4 | 20T Module 4 | |
| Operations in standby with 2x 7Ah batteries | Power saving (15m/min 15kgf) Normal (26m/min 15kgf) | Power saving (15m/min 9kgf) Normal (45m/min 9kgf) | |
| Half day2,5,6 | 118 | 63 | 189 | 130 | |
| Full day2,5,6 | 93 | 50 | 150 | 104 | |
| Collision Sensing | Electronic | Electronic | |
| Operating temperature range | -15°C to +50°C | -15°C to +50°C | |
| Onboard receiver type | Code-hopping multichannel receiver with selective add and delete | Code-hopping multichannel receiver with selective add and delete | |
| Receiver code storage capacity | 1500 Remotes7 | 1500 Remotes | |
| Receiver frequency | 433.92MHz | 433.92MHz | |
| Degree of protection | IP54 | IP54 |
continue reading
