Supply Voltage Range |
11-24V DC |
|
Maximum Current Draw |
300mA @ 12V DC |
|
Input/output Current Rating |
50mA (Open Collector) |
|
Input Sense Voltage Range |
0-24V DC (0-1.6V Low-input State, 5V-24V High-input State) |
|
SIM Card |
Micro-format, Activated MTN® SIM Card Supplied1, 2 |
|
Number of Configurable Input/Output Channels |
4 |
|
Call Buttons on Calling Module |
2 |
|
Call confirmation at Calling Module |
Yes |
|
Speech volume |
Adjustable at Calling Module using Call Buttons |
|
Calling Module illumination |
Call Buttons and labels with back-lit white LEDs |
|
Memory Capacity |
• 1500 Access numbers • 5000 Event logs • 20 Access Profiles • 1 Custom Welcoming SMS Message for New Access Numbers • 20 Custom Output Activation SMS Messages (From User to Device) • 30 Custom Input Notifi cation SMS/Email Messages (From Device to User) • 100 Visitor Time-barring Windows (Windows are the periods between two dates) • 30 Generic Time-barring Windows (Windows are weekly recurring) • 10 Output Activation Schedules (Schedules are weekly recurring) • 3 Daylight Saving Periods • 4 Input to Output Mapping Configurations |
|
Model Options |
GSM 2G: 850/900/1800/1900MHz (EDGE) GSM 3G: 900/2100MHz (EDGE) 900/2100MHz (UMTS) GSM 3G PENTA: 800/850/900/1900/2100MHz (UMTS) GSM 4G/LTE-CAT1: 900/2100MHz |
|
Degree of protection (G-Speak Ultra) |
IP40 |
|
Degree of protection (Calling Module) |
IP52 |
